参数Parameter

尺寸 Diameter

公差 Tolerance

单位Unit

长度 Length

1~2000

±0.2

mm

外经 OD

0.2~6

±0.03

内径 ID

0.06~5

±0.03

方形毛细管 Square capillary

参数Parameter

尺寸 Diameter

公差 Tolerance

单位Unit

长度 Length

1~2000

±0.2

mm

宽度 Width

0.3x0.3~6x6

±0.03

内径 ID

0.1x0.1~5x5

±0.03

异型毛细管/棒  Shaped Capillary Tube & Rod

形状

Shape

锥形管、D形管、椭圆管、梯形管、六边形管、三角型管、V型棒、U型棒

Conical tube, D-shaped tube, Elliptical tube, Trapezoidal tube, Hexagonal tube, Triangular tube, V-shaped rod, U-shaped rod,

孔径

Aperture

多孔（双孔、四孔、六孔，七孔，八孔，双排三孔）、椭圆孔、矩形、正方形、三角形，偏心孔、D型孔

Multi-hole (double holes, four holes, six holes, seven holes, eight holes, double row three holes), elliptical, rectangle, square, triangle, eccentric, D-shaped

羟基含量

Hydroxyl group

＜10ppm

材料 Material

石英玻璃

Quartz glass

说明 Specification

其他尺寸及公差可按客户要求生产

Other dimensions and tolerances can be manufactured according to customer requirements
